SJ-2000A Diamond Wire Saw Cutting Machine for Marble Granite Block Dressing

This machine has an independent guide rail on each of the four columns. The flywheel elevates and lowers along these guide rails. The flywheel works stably, which improves the service life of the diamond wire saw. Flywheel tension has a stable, constant stretch mode to enhance cutting accuracy. CNC system makes the man-machine interface easy and flexible. Diverse, complex,2-dimensional surfaces can be processed. Guide wheel uses a four-layer sealed protection system to greatly improve cutting accuracy. The linear cutting speed can be adjusted according to different cutting requirements. The protective cover is waterproof and highly durable.
Quantity:
  • SJ-2000A
  • WANLONG

SJ-2000A Numerical Control Wire Saw Machine:

This machine has an independent guide rail on each of the four columns. The flywheel elevates and lowers along these guide rails. The flywheel works stably, which improves the service life of the diamond wire saw. Flywheel tension has a stable, constant stretch mode to enhance cutting accuracy. CNC system makes the man-machine interface easy and flexible. Diverse, complex,2-dimensional surfaces can be processed. Guide wheel uses a four-layer sealed protection system to greatly improve cutting accuracy. The linear cutting speed can be adjusted according to different cutting requirements. The protective cover is waterproof and highly durable.


Standard Configuration

1. SIEMENS or indigenous premium beand main motor, 11KW

2. Adopts PANASONIC inverters for main motor, lifting motor and table, FUJI contactor

3. 360 degree auto rotation double layer table

4. Guide roller lifting system

5. Equiped encoder to instruct table movement for accurate slicing


Numerical Control Wire Saw Stone Machinery for Marble

2345截图20210714173914


SJ-2000A描述_04


Technical Parameters

1. SJ-2000A

Numerical Control Wire Saw

Model

Unit

SJ-2000A

Diameter of diamond wire

mm

Φ8.6-Φ10.8

Wire length

mm

14800

Main motor power

KW

7.5

Table dimensions(L×W)

mm

2000×1300

Max.cutting size(L×W×H)

mm

2000×2000×1500

Overall dimensions(L×W×H)

mm

6810×5354×3770

Water consumption

m³/h

6

Approximate weighe

kg

7500


CNC Panel

 Numerical Control Wire Saw Stone Machinery for Marble CNC Panel


PART OF WANLONG Stone Machinery Customers(Workshop)Numerical Control Wire Saw Stone Machinery for Marble OF WANLONG Stone Machinery


The synchronous lifting through intermediate drive makes its cutting with high stability and high efficiency. It is equipped with a 360° rotating worktable so it can dress four sides of block.
It is the ideal equipment for block dressing and to cut stone blocks into slices.



Detail Display

1、Scene processing

2、Computer controlled systemNumerical Control Wire Saw Stone Machinery for Marble Detail Display
